Fieldpiece MR45 1 HP Digital Refrigerant Recovery Unit

The Fieldpiece MR45INT is a high-performance digital refrigerant recovery unit with a 1 HP (0.75 kW) DC motor and integrated LCD display, designed to handle refrigerant recovery quickly in push/pull mode with a capacity of approximately 430 kg/hour. Compatible with A2L refrigerants such as R32 and many other common HVAC/R refrigerants, it is a reliable tool for professional technicians.

Info request Documents

Description

The Fieldpiece MR45INT represents a modern and advanced solution for refrigerant gas recovery in HVAC/R applications. Equipped with an intelligent variable-speed DC motor, this recovery unit automatically adjusts its power to optimize recovery in both liquid and vapor phases, delivering high performance even under variable supply voltages or suboptimal power conditions.

The large condenser and dual-cylinder oil-less compressor ensure efficient recovery, while the backlit LCD display with status messages makes it easy to monitor real-time operation. Thanks to its lightweight design (approximately 10 kg) with easily accessible connection ports, it is convenient to transport and use in the field. This model also includes an automatic purge system that maximizes recovery efficiency and minimizes residual refrigerant in the machine.

Technical features

1 HP (0.75 kW) DC motor with intelligent speed control for optimized performance.
Recovery capacity of approximately 430 kg/hour in push/pull mode with R410A refrigerant.
Backlit LCD display with status messages, easy to read even in low-light conditions.
Automated purge with single dial valve for auto-purge; simplifies operation and maximizes recovery.
Water-resistant, portable design (approx. 10 kg) with storage space for power cord.
Dual-cylinder oil-less compressor with long-life ceramic cylinders.
Operating voltage range: approximately 190–255 V AC single-phase (also compatible with voltage drops down to ~95 V).
Inlet and discharge pressure sensors with wide measurement range (approx. -76 cmHg to 600 psig).
Resolution and units: 5 kPa, 1 psig, 0.05 bar, 0.01 MPa.
High cut-off pressure: approx. 3850 kPa (558 psig) nominal.
Final vacuum: approx. 38 cmHg (14.9 inHg).
Dimensions: approx. 376 × 250 × 344 mm; Weight: approx. 10 kg.
Typical operating temperature range: ~0 °C – 43 °C; Storage: ~‑20 °C – 60 °C.
Suction port filtration: ~9 mm stainless steel mesh screen.
Compatible refrigerants: R32, R134a, R1234yf, R1234ze, R404A, R407C, R410A, and many other blends (including A2L class refrigerants).
Calibration system included (certificate compliant).

Applications

Refrigerant gas recovery from residential and commercial air conditioning systems and refrigeration units.
HVAC/R maintenance, disassembly, or retrofit operations where refrigerant needs to be extracted and contained.
Efficient recovery in liquid and vapor phases with intelligent motor control functions.
Direct field use thanks to lightweight and portable design, convenient for HVAC/R technicians on site.
Compatible with a wide range of refrigerants, including A2L refrigerants (e.g., R32, R1234yf).
